Lenze MOBILE DCU - Connections of MOBILE DCU S

Installation
Connections of MOBILE DCU S
PE conductor
5
Ò
62
EDSMDAG EN 2.0
5.7 Connections of MOBILE DCU S
5.7.1 PE conductor
PE
[mm
2
]
[AWG]
+ 2.5 ... 4
12 ... 10
Connection with non−insulated ring cable lug, M6
8 (Eco-Fix)
10
6.3 Nm
xxxxx
xxxxxxxx
DC4
xxxxx
xxxxxxxx
+
EMDAG029b
5.7.2 HV on−board supply system
X2
V
max
[V DC] [mm
2
]
[AWG]
21
1 +UG
848
2.5 ... 4
12 ... 10
2 −UG
EMDAG049b
