Radial forces and axial forces
P
ermissible axial force
If there is no radial force, the maximum axial force is 50% of the value in the table F
rad,max
F
ax, zul
= 0.5 x F
rad,max
.
If there is a
combinaon of radial force and axial force (F
rad
und F
ax
≠ 0), please
consult your responsible branch oce of Lenze.
Applicaon of forces
l
x
l
x
F
ax
F
rad
F
rad
F
ax
Addional load factor f
w
on the driv
e sha
0,4
0,6
0,8
1,0
1,2
1,4
0,0 0,2 0,4 0,6 0,8 1,0
f
W
x/l
Solid sha
Hollow sha
The values given in the tables relate to the force applicaon point at the centre of the sha
end and are minimum values that have been calculated according to the most unfavourable
condions (force
applicaon angle, mounng posion, direcon of rotaon). The values have
been calculated with a load capacity of c= 1.0.
In the case of
dierent condions of use, considerably greater forces can be
transmied. If so, consult the Lenze branch oce.
Technical data
Radial f
orces and axial forces
