Lenze MSEMA 080-32 Series - NFC Adapter; QUICKON Connector

NFC adapter
The sengs of the Lenze Smart Products can be made with an NFC-capable Android smart-
phone or a PC. If a PC is used t
o make the sengs, the »EASY Starter« engineering tool must
be used to do this (»EASY Advanced« soware licence). Communicaon takes place via the
NFC adapter. The adapter is connected to the PC at the USB interface.
NFC adapter
Version VPE Order code
Piece
Voltage supply on the input side via USB connecon of the PC
Diagnosc LEDs
hot plug-c
apable
1 EZAETF001
QUICKON connector
Nuts f
or QUICKON connecon
For fast and easy QUICKON connecon, the following nuts (counterparts) can be ed to the
connecng cable. No special tools are needed for installaon, only standard tools for stripping
the cable.
In the case of the capability for frequent connecons (>10 mes), QUICKON
c
onnector with nut is to be used.
Fig. 1: QUICKON connector with QUICKON nut
QUICKON nut
Version VPE Order code
Piece
Cable diameter: 6 … 10 mm 1 EWS0088
Cable diameter: 9 … 14 mm 1 EWS0089
QUICKON connector with QUICKON nut
Version VPE Order code
Piece
Can be plugged in and disconnected safe from touch
Cable diameter: 6 … 10 mm 1 EWS0090
Cable diameter: 9 … 14 mm 1 EWS0091
Accessories
NF
C adapter
56
