Lenze SM004S - Parameter Menu

Lenze 13466147 EDBSM01 v19 EN 31
Commissioning 4
4.3 Parameter Menu
No. Parameter Name Range of Adjustment
Factory
Default
01 LINE VOLTAGE
HIGH (01)
LOW (02)
HIGH (01)
02 CARRIER FREQUENCY
4kHz (01)
6 kHz (02)
8 kHz (03)
10 kHz (04)
6 kHz (02)
03 START METHOD
NORMAL (01)
START ON POWER UP (02)
START WITH DC BRAKE (03)
AUTO RESTART WITH DC BRAKE (04)
FLYING RESTART 1 (05)
FLYING RESTART 2 (06)
FLYING RESTART 3 (07)
NORMAL (01)
04 STOP METHOD
COAST (01)
COAST WITH DC BRAKE (02)
RAMP (03)
RAMP WITH DC BRAKE (04)
COAST (01)
05
STANDARD SPEED
SOURCE
KEYPAD (01),
PRESET #1 (02),
0-10 VDC (03),
4-20 mA (04)
KEYPAD (01)
06 RELAY OUTPUT
NONE (01), RUN (02), FAULT (03),
INVERSE FAULT (04), FAULT LOCKOUT (05),
AT SET SPEED (06), ABOVE PRESET #3 (07),
CURRENT LIMIT (08), AUTO SPEED (09),
REVERSE (10)
NONE (01)
10
TB-13A FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #1 (04),
START FORWARD (05),RUN REVERSE (06),
START REVERSE (07),
EXTERNAL FAULT (08),
INVERSE EXT FAULT (09),
AUXILIARY STOP (10),
ACCEL/DECEL #2 (11)
NONE (01)
11
TB-13B FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #2 (04), DECREASE FREQ (05),
START FORWARD (06), JOG FORWARD (07),
JOG REVERSE (08), EXTERNAL FAULT (09),
INVERSE EXT FAULT (10), AUX. STOP (11),
ACCEL/DECEL #2 (12), REMOTE KEYPAD (13)
NONE (01)
