4 Commissioning
P05 STANDARD SPEED SOURCE
P05 selects the speed reference source when the drive is in STANDARD speed mode. The following
speed references can be selected:
01 KEYPAD: Use the p and q buttons to scroll to the desired speed.
02 PRESET SPEED #1: Drive will operate at the frequency set in Parameter 31.
03 0-10 VDC: Drive will respond to a 0-10 VDC signal wired to TB-5 (+) and TB-2 (-).
04 4-20 mA: Drive will respond to a 4-20 mA signal wired to TB-25 (+) and TB-2 (-).
P06 RELAY OUTPUT
P06 selects the status indication for the normally open relay output at TB-16 and TB-17:
01 NONE: Disables the relay output.
02 RUN: Closes upon a START command. Opens if the drive is in a STOP state, the drive faults, or
input power is removed. DC braking is considered a STOP state.
03 FAULT: Closes if there is no fault condition. Opens if the drive faults, or input power is removed.
04 INVERSE FAULT: Closes if the drive faults. Opens if there is no fault condition.
05 FAULT LOCKOUT: Closes when input power is applied. Opens if three restart attempts are
unsuccessful, or if input power is removed.
06 AT SET SPEED: Closes if the drive is within + 0.5 Hz of the speed setpoint.
07 ABOVE PRESET SPEED #3: Closes if the output frequency exceeds PRESET SPEED #3 (Parameter
33). Opens if the output frequency is equal to or less than PRESET SPEED #3.
08 CURRENT LIMIT: Closes if the output current exceeds the CURRENT LIMIT setting. Opens if the
output current is equal to or less than CURRENT LIMIT (see Parameter 25).
09 AUTOMATIC SPEED MODE: Closes if an AUTOMATIC (terminal strip) speed reference is active.
Opens if a STANDARD (Parameter 5) speed reference is active.
10 REVERSE: Closes when reverse rotation is active. Opens when forward rotation is active (see
Parameter 17 - ROTATION DIRECTION).
