2.2 Ratings
Type Power
[kW]
Mains Output Current
Voltage, frequency Current
[A]
I
r
I
max
for 60 s
[A]
(1)
[A]
(2)
[A]
(1)
[A]
(2)
ESMD251W2SFA 0.25
1/N/PE 230/240 V
2/PE 230/240 V
(180 V - 0% … 264 V + 0 %)
50/60 Hz
(48 Hz - 0 % … 62 Hz + 0 %)
3.4 1.7 1.6 2.6 2.4
ESMD371W2SFA 0.37 5.0 2.4 2.2 3.6 3.3
ESMD551W2SFA 0.55 6.0 3.0 2.8 4.5 4.2
ESMD751W2SFA 0.75 9.0 4.0 3.7 6.0 5.5
ESMD152W2SFA 1.5 14.0 7.0 6.4 10.5 9.6
ESMD222W2SFA 2.2 21.0 9.5 8.7 14.3 13.1
ESMD371W2TXA 0.37
3/PE 230/240 V
(180 V - 0% … 264 V + 0 %)
50/60 Hz
(48 Hz - 0 % … 62 Hz + 0 %)
2.7 2.4 2.2 3.6 3.3
ESMD751W2TXA 0.75 5.1 4.2 3.9 6.3 5.9
ESMD112W2TXA 1.1 6.9 6.0 5.5 9.0 8.3
ESMD152W2TXA 1.5 7.9 7.0 6.4 10.5 9.6
ESMD222W2TXA 2.2 11.0 9.6 8.8 14.4 13.2
ESMD302W2TXA 3.0 13.5 12.0 11.0 18.0 16.5
ESMD402W2TXA 4.0 17.1 15.2 14.0 22.8 21.0
(1) For rated mains voltage and carrier frequencies 4, 6, 8 kHz
(2) For rated mains voltage and carrier frequency 10 kHz
