Antenna connecon
For IoT Gateways x520, x530 and x540 only.
NOTICE
Observe minimum clearance during installaon.
▶
The minimum distance from the antenna to persons must be 200 mm and must not be installed or
operated together with other antennas or transmiers.
IoT Gateway x530 (LAN + 4G) is provided with 2 SMA antenna connecons. The one closest to the
power connecon is the MAIN. The other connecon is the DIV. Always connect an antenna to the
MAIN. The connecon of an antenna to the DIV is oponal.
The IoT Gateway x540 (LAN + Wi-Fi + 4G) is provided with 2 SMA antenna connecons. The one
closest to the power connecon is for 4G. The other connecon is for Wi-Fi.
Mounng the monopole antenna/plug-on antenna
x520 x530 x540
RP-SMA monopole antenna
(x5ZAG010000S)
LTE-SMA plug-on antenna
(x5ZAG030000S)
le: RP-SMA monopole antenna
(x5ZAG010000S)
right: LTE-SMA plug-on antenna
(x5ZAG030000S)
