Diagnoscs and fault eliminaon
LED status display
The status LED directly above the LAN ports shows the current status of the IoT Gateway.
Aer switching on, the IoT Gateway passes through various states to establish a connecon to the
X4 Remote Plaorm. The nal status is signalled aer about 2 minutes.
Status LED Status/meaning
Constant
Boong (this may take 1 - 2 minutes)/not registered
1 pulse
Waing for Internet access.
3 pulses
LAN/WAN conict
4 pulses
Removed from plaorm.
à Insert USB data carrier to register again.
5 pulses
Previously registered in X4 Remote Plaorm.
à Remove from X4 Remote Plaorm and register again.
1 pulse
Establish connecon to X4 Remote Plaorm.
2 pulses
Set up a VPN connecon.
Constant
Acve VPN connecon to X4 Remote Plaorm.
The signal LED is only available on the Wi-Fi/4G versions and shows informaon on recepon.
Signal LED Status/meaning
Blinking
Inializaon
Constant
Connected, good recepon.
Constant
Connected, medium recepon.
Constant
Connected, bad recepon.
1 pulse
No recepon or no network connecon possible.
2 pulses
Device cannot unlock the SIM card. The PIN code may be incorrect or the PUK code may be required
because the wrong PIN code was entered three mes.
à Check PIN code:
Open the conguraon le (router.conf) with a text editor and search for "pincode =". If the PIN code
entered behind it is incorrect, change it and load the new conguraon into the device. Alternavely,
create a new conguraon le.
à Unlock locked SIM card with a PUK code:
Insert the SIM card into a mobile phone and enter the PUK code when prompted. You received the PUK
code together with your SIM card. Contact your provider if you have lost both codes.
4 pulses
The SIM card is invalid or missing.
à Check that the SIM card is correctly inserted in the SIM card slot.
à If correctly placed, insert the SIM card into a mobile phone and check that the SIM card works
properly. If this is not the case, contact your provider.
Diagnoscs and fault eliminaon
LED status display
