Transparent HTTP Tunnel: If you want to use your own RS-485 device, you can use UART commands to
build a Transparent HTTP Tunnel. The UART commands will be sent through HTTP tunnel established
between the RS-485 device and the linked camera. For detailed application notes, please refer to URL
Commands on page 106 or http://www.LevelOne.com/downloadfiles/faq/videoserver/UART_HTTP_
Tunnel.pdf.
Preset Positions
If you select DynaDome/SmartDOME, Lilin PIH-7x00, or Pelco D protocol as the PTZ driver and click
the Save button, the Preset Position button will be enabled. Click Preset Position to open the settings
page. You can also select preset positions for the camera to patrol. A total of 20 preset positions can be
congured.
Please follow the steps below to preset a position:
1. Adjust the shooting area to the desired position using the buttons on the right side of the window.
2. Enter a name for the preset position, which allows for up to forty characters. Click Add to enable the
settings. The preset positions will be displayed under the Preset Location list on the left-hand side.
3. To add additional preset positions, please repeat steps 1~2.
4. To remove a preset position from the list, select it from the drop-down list and click Delete.
5. The preset positions will also displayed on the main page. Please refer to the illustration on the next
page.
6. Click Save to enable the settings.
Functions are the same
as the Control Panel on
the home page
1
2
4
6
2
