Hardware Manual
16
Step 5: Waterproof the Cable Connection
Depending on the camera model, the Ethernet cable or the “pigtail” of the camera may either
have the RJ-45 connector.
RJ-45 Ethernet Cable
When using the RJ-45 Ethernet cable, follow the procedures below to waterproof the cable
connection:
1. Detach the cable gland as shown below.
2. On the network side cable, insert the clamping nut through the Ethernet cable.
3. Insert the sealing rubber and claw through the Ethernet cable.
To Next Page
