LevelOne FCS-4102 - Technical Specifications

Network Camera User’s Manual
60/61
B. Technical specifications
- System
RAM: 4G DDRⅢ
ROM: 16MB Flash ROM
- Protocol
TCP/IP, HTTP,UDP, SMTP, FTP, DDNS,
UPnP, Telnet, NTP, PPPoE, RTSP,
RTP,RTCP,DHCP and DNS
- Infrared Led
Auto/Manual mode, 10~12 M visible
Daylight sensor, angle +/-65, wave length
400~700nm
Spectral band width 42nm, Peak emission
wavelength 850nm
- Lens
Fixed focal with fine tuning, 4.0mm+/-5%,
F/1.5+/-5%
View angle
D:80.4°+/-5° H:65.4°+/-5° V:49.9°+/-5°
- Camera specification
1/2.7 inch color CMOS sensor, Resolution:
1920x1080 1.0Lux/F2.0
AGC, AWB, AEC
- Video Resolution
Up to 30 frames at 176x144, 320x240,
640x480, 1280x800, 1280x1024,
1920x1080
- Algorithm supported
H.264/MPEG4/MJPEG dual codec for
streaming video
JPEG for still image
- Audio
AMR/AAC/G.711
Omni-directional Microphone
Support 2 way audio
- Physical
10 baseT or 100 baseT Fast Ethernet auto
negotiation
- Power
Input: 100-240VAC, 50/60Hz, 0.7A
Output: 12VDC, 1.5A
Consumption: Max 8 W
Support 802.3af compliant Power over
Ethernet
- EMI & Safety
CE, FCC
- Dimension
Height : 66.5mm,
Diameter : 93.8mm(excluding 3 mounts)
- Pan/Tilt angle
Support auto tracking function
Support multi - direction movement
Pan: 200°(-100°~100°)
Tilt: 70°(20°~90°)
- I/O Interface
RJ-45
DI
DO
Mic. in
Audio out
DC Power
Micro SD(inside camera)
- Weight
NET. 500g
- Operating Environment
Temperature : -5 - 45℃
Humidity: 85% RH
