2. Installation
9
Hardware installation
1. Connect the Ethernet adapters USB end to a free USB port of your computer. Then a
pop-up message will appear in the notification area indicating the installation is
complete.
* Actual strings depend on your operation system. These screen shots are from Windows
7
and might vary slightly for each operation system.
2. Connect an Ethernet cable to the Ethernet port on the adapter.
3. Connect the other end of the Ethernet cable to your network hub, switch or router.
Verifying the Driver Installation
on Windows
Operating Systems
Once you finish the installation, you can open Windows
Device Manager to
verify if your Ethernet Adapter is properly installed. To access the Device Manager:
On Windows
7: Right-click Computer on the desktop and click System
Properties>Device Manager
On Windows
XP: Right-click My Computer on the desktop and click
Properties > (Hardware) > Device Manager.
In the Network adapters group, an item named ASIX AX88772B USB2.0 to Fast
Ethernet Adapter should be displayed.
If there is a question or exclamation mark next to that item, then the driver is not
properly installed. Please delete the item, select the Delete the driver software for
this device option (if provided), unplug the adapter from your computer and then
repeat the installation steps.

Other manuals for LevelOne USB-0301

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LevelOne USB-0301 and is the answer not in the manual?

LevelOne USB-0301 Specifications

Network Specifications IconNetwork Specifications
network standardsIEEE 802.3: 10Base-T, IEEE 802.3u: 100Base-T
data transfer ratesEthernet: 10Mbps (Half/Full Duplex), Fast Ethernet: 100Mbps (Half/Full Duplex)
network interfaceFemale RJ45 jack
Power IconPower
power consumption850mW
power managementSuspend mode, hibernation mode
Operating Environment IconOperating Environment
operating system supportWindows® 2000, XP, Vista™, Windows®7; Mac OS X 10.x
operating temperature0°C to 70°C
System Memory IconSystem Memory
RAMEmbedded 20KB SRAM for RX packet buffering and 20KB SRAM for TX packet buffering
Weight and Dimensions IconWeight and Dimensions
dimensions66 mm x 22 mm x 15 mm
weight25g
