LevelOne USB-0301 User Manual

4. Specifications
13
4. Specifications
General
Host Interface
USB 2.0 (1.1 compliant)
Operating System Support
 Windows

XP, Windows

7, Windows

8
 Mac

OS10.5 and later.
Ports and Connectors
Upstream
1 x Upstream USB Standard Type A plug
Ethernet
1 x Ethernet Port (RJ-45 connector)
LED
Link LED (Amber)
 On: When connection to a 100Mbps network
 Off: When connection to a 10Mbps network
Status LED (Green)
 On/Blinking: LAN activity.
 Off: No network traffic.
Power
Power Mode
USB Bus -powered
Power Consumption
 Operating Mode: 250 mA
 Suspend Mode : 5 mA
Physical Specifications
Housing Material
ABS (Plastic)
Dimensions
 Main body without cable: 65 mm (L) x 23 mm(W)x 15 mm (H)
 Main body with cable: 75 mm (L) x 23 mm(W)x 15 mm (H)
Weight
Approximately 43 g (including cable)
Environmental Specifications
Operating Temperature
10-40°C
Storage Temperature
-10~80°C

LevelOne USB-0301 Specifications

Network Specifications

network standards	IEEE 802.3: 10Base-T, IEEE 802.3u: 100Base-T
data transfer rates	Ethernet: 10Mbps (Half/Full Duplex), Fast Ethernet: 100Mbps (Half/Full Duplex)
network interface	Female RJ45 jack

Power

power consumption	850mW
power management	Suspend mode, hibernation mode

Operating Environment

operating system support	Windows® 2000, XP, Vista™, Windows®7; Mac OS X 10.x
operating temperature	0°C to 70°C

System Memory

RAM	Embedded 20KB SRAM for RX packet buffering and 20KB SRAM for TX packet buffering

Weight and Dimensions

dimensions	66 mm x 22 mm x 15 mm
weight	25g
