LevelOne WAP-6003 - Package Information; Hardware Configuration

6
Routing Protocol
Static route, dynamic route (RIP v1/v2)
Management
SNMP, syslog,
Administration
Web-based UI, remote login, backup/restore setting
Environment & Certification
Package
Information
DC 5V/1A power adapter, Quick Installation Guide
1. Package
Information
Device dimension (mm) 185 x 119 x 32 mm
Operation Temp.
Temp.: 0~40oC, Humidity 10%~90% non-condensing
Storage Temp.
Temp.: -10~70oC, Humidity: 0~95% non-condensing
EMI Certification
CE/FCC compliance
RoHS
RoHS compliance
*Specifications are subject to change without prior notice.
1.3 Hardware Configuration
Figure 2-1 Front Panel
Auto MDI/MDIX RJ-45 Ports
Automatically sense the types of LAN
when connecting to Ethernet
Power Jack
Antenna
Reset Button
