LevelOne WAP-6221 - Installation

-3-
Installation
LED/Button/Interface
Description
WIFI SSID Broadcast
ON/OFF
To turn on or off the WIFI SSID Broadcast
Reset to Defaults
With the AP powered on, press the Reset
button for 10 ~ 12 seconds until the Signal
Strength LED blink faster than ever. The
AP will restart itself and reset the device to
factory default settings.
LAN port
The LAN port is used to connect to network
devices, such as a switch or PC / NB
USB port
Charge USB devices (5V1A)
WAN/POE Port
The WAN/POE port is used to connect to
network devices, such as a POE switch
OR POE adapter to power the device
( IEEE802.3af ) 48 VDC. (POE adapter
unit is to be ordered separately)
