2.4 Overview of Parameter Configuration
Table 4 shows the standard (“Default”) and possible parameter configurations of the clamp-on flowmeters.
This user manual is dealing with the standard configuration. For setting up other configurations the Levitronix
®
Service Software is needed. Consult the Levtronix
Service Software manual for more detailed description.
Default values are:
LFSC-i06X=1 lpm LFSC-i10X=20 l/min LFSC-i16X=20 lpm
LFSC-i19X=50 lpm LFSC-i25X=80 lpm LFSC-i35X=160 lpm
Flow cut to 0 below this percentage of full-scale
If cutoff 0% is chosen, negative flow becomes visible
Kinematic Viscosity
(= Dynamic Visc. / Density)
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Set Volume Counter to zero
Flow alarm High
Flow alarm Low
Vol. counter alarm H
Vol. counter alarm HH
Vol. counter Pulse
Measurement Error
Flow as Frequency
Bubble detect
Custom Output
- Upper flow limit detection
- Lower flow limit detection
- Flow volume detection first value (one-time)
- Flow volume detection second value
- Pulse per volume
- Error signal (empty sensor etc.)
- Flow as Frequency output (100% of full-scale = 1 kHz)
- Bubble detected signal
- Bits of equipment status can be OR-ed on the output
Can be used to get tolerance to noise.
Alarm setting In percentage of full-scale.
N.O. = normally open
N.C. = normally closed
Alarm setting In percentage of full-scale.
N.O. = normally open
N.C. = normally closed
Volume counter enable
(activation box)
These are settings for volume detection (integration of
flow).
Has to be active for the options “ Vol. Counter Alarm H”,
“Vol. Counter Alarm HH” and “Vol. Counter Pulse”.
Volume counter pulse length
Volume counter alarm enable
(activation box)
-> Settings for one-time volume detection.
-> Volume = “Volume unit” x “Multiplier factor” x “Vol.
Counter Alarm H“ value”
-> Has to be active for the options “Vol. Counter Alarm
H”, “Vol. Counter Alarm HH”.
Value (Volume counter alarm H)
N.O. = normally open
N.C. = normally closed
Value (Volume counter alarm HH)
N.O. = normally open
N.C. = normally closed
Measurement
Error Settings
Instant Measurement Error Ignore
Time
During this time instant measurement errors are ignored.
If an instant measurement error stays active for longer
time than this time, measurement error arises.
Flow Level on Measurement Error
Signal level of analog output and flow, when
measurement error arises
Bubble
Detection
Settings
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Table 4: Overview of parameters
