Levitronix PuraLev 2000SU User Manual

User Manual for PuraLev
®
2000SU
www.levitronix.com
PL-4034-00, Rev02, DCO# 20-144
9
2.6 Maximum Static Pressure for Pump Heads
Figure 8: Specification for maximum static pressure for single-use pump head DCP-2000.2
(Pressure limits only valid for pump head mounted on motor)
0
20
40
60
80
100
77 87 97 107 117 127 137
0
1
2
3
4
5
6
7
8
25 30 35 40 45 50 55 60
[psi]
[°F]
[bar]
Liquid Temperature in [°C]
Max. Static Pressure for DCP-2000.2
Burst pressure at ambient temperature = 25 C is >15 bar after gamma radiation of 40 kGy
and 2 times temperature cycling between -25 C and +75 C.
Note: Pressure limit only valid for pumphead mounted on motor. Values only valid after
Gamma radiation doses of < 40 kGy.
