2.2 CONSOLE UNIT INSTALLATION
1. Choose a position where the operator will be able to see the anchor and windlass when
using the AA150.
2. The console sho
equipment transmitting or cables carrying radio signals eg VHF radios, cables and
antennas or radar antenna and at least 6ft (2m) away from any SSB equipment.
3. The console should be mounted where it is protected from the elements. The AA150
is splash proof and should not be placed in a position where it is likely to be immersed in
water.
4. The panel for mounting the instrument should be 3mm to 19mm (1/8 to 3/4 inch) thick.
instrument panel in the selected location.
insert the instrument into the hole until the
outside mounting wall.
instrument. N
8. Tighten the mounting nut until the
bracket is secure.
Fig 7 Console Installation
10
Before starting check with the AutoAnchor manufacturer or supplier, that it is
possible to t the sensor and magnet to your horizontal windlass.
For an accurate rope count the rode must run between the sensor and magnet. On
manufacturer.
This provides an accurate count of
rode deployed but during retrieval the display may be incorrect because it cannot
allow for the stretch in the rope.
2.1.8 INSTALLATION HORIZONTAL WINDLASS - ROPE & CHAIN
2.2.1 Multiple Console Unit Installation
iple stations or the AA150 can be
installed with other AutoAnchor products. All wiring for multiple AutoAnchor stations is
colour matched and run in parallel.
diagram and/or your supplier for details.
All cables must be connected.
All battery and motor cables must be ring type, insulate
installed no closer than 1ft (300mm) away from the sensor head.
All main power conductors and terminations are to be installed according to the windlass
[3013] Soft Seal or CRC [2043] Plasticoat 70. Insulation must be used to protect allInsulation must be used to protect all
terminals.
To reduce the potential for interference all cables must be located at least 1.5ft (500mm)
away from any equipment transmitting or cables carrying radio signals eg VHF or SSB
radios, cables and antennas or radar antennas.
tied in place with cable ties.
Multiple Console Wiring
potential differences do not occur along the ground connection. This can cause incorrect
counting. Ensure consoles are star grounded and that there are no other high current paths
between consoles. All wiring for multiple installations is run in parallel. Refer to wiring
diagrams for further details.
2.3 WIRING
11
2.5.3 CONNECTION TO LOW CURRENT WINDLASS DRIVES
When connecting to solid state switching or other low current windlass d
should be installed close to the windlass control
not on the AA150.
See the note below re wiring for multiple console installations.
For dual console operation, the sensor must be reset before calibrating the consoles. To do
clear within 4 seconds. rE will be displayed during the second clearing indicating the reset
is okay.
