Pro-Series /Fish Windlasses

Product manual

Owners Installations, Operation & servicing manual

Installations, Betriebs & Wartungshandbuch

Manuel d’installation, de fonctionnement et d’entretien

Manual de instalación, Operación y servicio

Guida all’installazione, all’uso e alla manutenzione

Bruksanvisning för installation, dri och service

GB

D

I

E

F

S

Table of Contents

Other manuals for Lewmar Pro Series

Owners Installation, Operation & Basic Servicing Manual15 pages

Questions and Answers

R
Richard TuckerJul 28, 2025
Why is my Lewmar Pro Marine Equipment operating sluggishly?
- K
  Kimberly MorenoJul 28, 2025
  If your Lewmar Marine Equipment is operating sluggishly, several factors could be at play. First, check if the windlass is overloaded and ease the load. Ensure the battery is well-charged. If the issue persists, measure the voltage across the motor leads while the windlass is on. A significant voltage drop indicates undersized or corroded cables, poor connections, or resistance in the battery isolation switch or solenoid. Finally, verify that the voltage is correct; if it is, the motor may be defective and require replacement.
S
scott75Aug 5, 2025
What to do if my Lewmar Pro Marine Equipment fails to operate?
- A
  Arthur SweeneyAug 5, 2025
  If your Lewmar Marine Equipment fails to operate, begin by checking for voltage at the input terminals of the contactor and switch(es). If there's no voltage, inspect the circuit breaker/isolator switch and any fuses. Next, while operating the switch, check for voltage at the positive switch terminal on the solenoid. If there's no voltage, the switch or its wiring is likely defective. If voltage is present, keep the switch activated and check for voltage at the main output terminal on the contactor. If there's no voltage, inspect the contactor coil ground circuit; if it's okay, replace the contactor. Finally, check the voltage at the motor. If voltage is present but the motor doesn't run, the motor is defective.
H
hturnerAug 12, 2025
How to stop anchor rode paying out independently on Lewmar Pro?
- G
  gonzalezdebraAug 12, 2025
  If the anchor rode on your Lewmar Marine Equipment pays out independently when the windlass is not in use, tighten the clutch nut using the provided tool. Always secure the anchor rode independently of the windlass when it is not being actively used for deployment or retrieval.
I
ipenningtonAug 19, 2025
What to do if Lewmar Marine Equipment (Pro-Fish) anchor rode pays out independently?
- R
  rjonesSep 12, 2025
  If the anchor rode on your Lewmar Marine Equipment (Pro-Fish model) pays out independently while the windlass is not in use, briefly operate the UP button to fully re-engage the internal clutch mechanism.

Summary

Safety Notice

Windlass General Safety

General safety precautions and responsibilities for windlass operation and maintenance.

Fitting Safety

Requirements and warnings regarding the proper installation of the windlass.

Electrical Safety

Safety guidelines for the electrical installation of the windlass by a qualified engineer.

Electrical Wiring

Electric Cable Selection

Wiring Guidelines

Guidance on wiring systems, insulation, polarity, and overload protection with circuit breakers.

Operation

Manual Controlled Freefall Operation

Guides for manual anchor deployment using freefall for Pro-Fish and Pro-Series models.

Manual Anchor Recovery

Procedure for manually recovering the anchor using a wrench, including safety warnings.

Powered Anchor Up;Down Procedures

Instructions for powered anchor hoisting and lowering for Pro-Fish and Pro-Series models.

General Windlass Operating Procedures

Servicing

Servicing Schedule

Gypsy Replacement;Service

Troubleshooting

Anchor Rode Pays Out Independently

Failure or Sluggish Operation

Diagnoses common causes of windlass failure or slow operation, focusing on electrical issues.

Complete Failure to Operate

Troubleshooting steps for complete windlass failure, checking voltage, switches, and motor.

Summary

Safety Notice

Windlass General Safety

General safety precautions and responsibilities for windlass operation and maintenance.

Fitting Safety

Requirements and warnings regarding the proper installation of the windlass.

Electrical Safety

Safety guidelines for the electrical installation of the windlass by a qualified engineer.

Electrical Wiring

Electric Cable Selection

Wiring Guidelines

Guidance on wiring systems, insulation, polarity, and overload protection with circuit breakers.

Operation

Manual Controlled Freefall Operation

Guides for manual anchor deployment using freefall for Pro-Fish and Pro-Series models.

Manual Anchor Recovery

Procedure for manually recovering the anchor using a wrench, including safety warnings.

Powered Anchor Up;Down Procedures

Instructions for powered anchor hoisting and lowering for Pro-Fish and Pro-Series models.

General Windlass Operating Procedures

Servicing

Servicing Schedule

Gypsy Replacement;Service

Troubleshooting

Anchor Rode Pays Out Independently

Failure or Sluggish Operation

Diagnoses common causes of windlass failure or slow operation, focusing on electrical issues.

Complete Failure to Operate

Troubleshooting steps for complete windlass failure, checking voltage, switches, and motor.

Lewmar Pro Series Specifications

General

Series	Pro Series
Gear Type	Spur Gear
Voltage	12V
Type	Electric Windlass
Handle Options	Manual Override (varies by model)
Mounting	Horizontal
