Lexicon MPX 100 User Manual

19
Gate
In the MPX 100, the Gate program pro-
vides a fairly constant sound with no decay
until the reverb is cut off abruptly. This pro-
gram works well on percussion — particu-
larly on snare and toms, but be sure to
experiment with other sound sources as well.
* Note that audio is muted briefly when Duration is
altered with Adjust.
Gated reverbs were originally created by feeding a reverb, such as a metal plate,
through an analog gate device. The decay time was set to instant, and the hold time
varied the duration of the sound.
Gate VARIATIONs Adjust Tap
9 Straight Gate Duration* –
10 Drum Gate Duration* –
11 Slope Down Duration* –
12 140 ms Gate High Cut Predelay (1/32 Note)
13 240 ms Gate High Cut Predelay (1/32 Note)
14 340 ms Gate High Cut Predelay (1/32 Note)
15 440 ms Gate High Cut Predelay (1/32 Note)
16 540 ms Gate High Cut Predelay (1/32 Note)

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
