Lexicon MPX 100 User Manual

41
The Special FX variations showcase the
flexibility and creative possibilities of the
MPX 100. Adjust is completely different in
each of the Variations, so be sure to experi-
ment with all of them.
Special FX
Delay, Echo VARIATIONs Adjust Tap
1 Infinite Reverb High Cut Echo
2 The Abyss ± Pitch Bend –
3 Jet Flange Tone Rate (Whole Note)
4 Chorus Verb High Cut –
5 Rotary Delay Dly/Echo Time: 0-150ms+Fbk Rate (1/4 Note)
6 Fader Verb Input Volume Echo
7 PCM 60 - LgSize Decay Time –
8 LowRumble Decay Time –
9 Ducking Reverb Decay Time –
10 Ducking Chorus>Delay ± Resonance –
11 Ducking Triplets Delay/Echo Feedback –
12 Subdividing Delay Beat Value: 1/32-Whole Note Delay Time
13 Panning Delays Delay/Echo Feedback Dly Time, Pan Rate
14 Dream Sequence ± Shift Amount –
15 Infinite Repeat Feedback: 0-Infinite Dly Time (Whole Note)
16 Diffusor Diffusion –

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
