Lexicon MPX 100 User Manual

21
Chamber
In the MPX 100, the stereo Chamber
program produces an even, relatively dimen-
sionless reverberation, with little change in
color as the sound decays. The initial diffu-
sion is similar to the Hall program, but the
sense of space and size is much less obvi-
ous. This characteristic, along with the low
color of the decay tail makes Chamber useful
on a wide range of material. It is especially
useful on spoken voice, giving a noticeable
increase in loudness with very low color.
Historically, recording studio chambers were often oddly shaped rooms with a
loudspeaker and set of microphones to pick up the ambience in various parts of the
room.
Chamber VARIATIONs Adjust Tap
9 Brick Wall Liveness –
10 Basement Liveness –
11 Live Concert Liveness Eko Delay
12 Percussion 1 Liveness –
13 Percussion 2 Liveness –
14 Live Chamber Liveness –
15 Vocal 1 Liveness Eko Delay
16 Vocal 2 Liveness Eko Delay

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
