Lexicon MPX 100 User Manual

31
When using any type of delay or echo
effects with music, always pay attention to
the way the repeats fall rhythmically to the
beat. The most effective delay and echo
patterns are those that lock in with the
tempo of the tune.
Delay, Echo VARIATIONs Adjust Tap
1 Mono Quarter-Note Delay/Echo Feedback Delay Time
2 Stereo Quarter-Note Delay/Echo Feedback Delay Time
3 Triplet Shuffle Delay/Echo Feedback Delay Time
4 Dotted Eighth-Note Delay/Echo Feedback Delay Time
5 Eighth-Note and Triplet Delay/Echo Feedback Delay Time
6 Ping Pong Quarter-Note Delay/Echo Feedback Delay Time
7 Triplet Rhythm 1 Delay/Echo Feedback Delay Time
8 Triplet Rhythm 2 Delay/Echo Feedback Delay Time
9 Mono Delay/Echo Time: 0-5.5sec
10 Stereo Delay/Echo Time: 0-2.7sec
11 Tape Slap Delay/Echo Time: 3 3/4 to 30ips
12 Multi Bounce Delay/Echo Time: 0-100ms
13 Multi Linear Delay/Echo Time: 0-400ms
14 Multi Inverse Delay/Echo Time: 0-400ms
15 Multi Repeat Delay/Echo Time: 0-150ms + Fbk
16 Multi Pong Delay/Echo Time: 0-200ms + Fbk

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
