2 Remove the imaging unit.
Warning—Potential Damage: Do not expose the imaging
unit to direct light for more than 10 minutes. Extended
exposure to light may cause print quality problems.
Warning—Potential Damage: Do not touch the
photoconductor drum. Doing so may aect the quality of
future print jobs.
3 Remove the jammed paper.
CAUTION—HOT SURFACE: The inside of the printer
might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching
it.
Note: Make sure that all paper fragments are removed.
4 Insert the imaging unit.
5 Close the door.
Paper jam in the rear door
1 Open the rear door.
CAUTION—HOT SURFACE: The inside of the printer
might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching
it.
2 Open the fuser access door.
3 Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
4 Close the fuser access door.
5 Close the rear door.
Paper jam in the duplex unit
1 Remove the duplex unit, and then remove the jammed paper.
Warning—Potential Damage: To prevent damage from
electrostatic discharge, touch any exposed metal frame of
the printer before accessing or touching interior areas of the
printer.
5

Lexmark B2236dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print margins (top, bottom, right, left)	5 mm
Print speed (black, normal quality, A4/US Letter)	36 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Cables included	AC
Included cartridge capacity (black)	700 pages
Display	LCD
Certification	ICES-003 B, BSMI B, VCCI B, US FDA, UL 60950-1, FCC B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC, GS, EC 1275, MET-I, ISO 532B, ECMA-370, EAC, SII, TER
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	20 - 75 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Total input capacity	251 sheets
Total output capacity	150 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	IPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, AppleTalk, TCP, UDP
Package depth	443 mm
Package width	418 mm
Package height	312 mm
Package weight	9620 g
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2500 pages per month
Page description languages	PCL 5e, PCL 6
Average cartridge yield (black)	1200 pages
Internal memory	256 MB
Noise level (ready)	14 dB
Processor frequency	1000 MHz
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	50 dB
Other operating systems supported	Novell Open Enterprise Server
Server operating systems supported	Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Power consumption (ready)	4 W
Power consumption (standby)	1.2 W
Power consumption (printing)	460 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	333 mm
Width	355 mm
Height	215 mm
Weight	6800 g
