Physical specifications
Dimensions for single‑function printer (unpackaged)
Printer model Height Width Depth Weight
Printer (unpackaged) without options
CS310n
*
291.2 mm (11.5 in.) 442 mm (17.4 in.) 406.7 mm (16.0 in.) 20.1 kg (44.3 lb)
CS310dn
*
291.2 mm (11.5 in.) 442 mm (17.4 in.) 406.7 mm (16.0 in.) 20.3 kg (44.8 lb)
CS410n, CS410dn
*
291.2 mm (11.5 in.) 442 mm (17.4 in.) 406.7 mm (16.0 in.) 20.5 kg (45.2 lb)
CS510de
*
306.2 mm (12.1 in.) 442 mm (17.4 in.) 406.7 mm (16.0 in.) 20.9 kg (46.1 lb)
Printer (unpackaged) with options
CS410dtn with
650‑sheet duo tray
422.3 mm (16.6 in.) 442 mm (17.4 in.) 416.4 mm (16.4 in.) 24.7 kg (54.5 lb)
CS510dtn with
550‑sheet duo tray
436.9 mm (17.2 in.) 442 mm (17.4 in.) 416.4 mm (16.4 in.) 25.1 kg (55.3 lb)
*
The desktop footprint dimensions are 424.2 mm (16.7 in.) wide by 398.8 mm (15.7 in.) deep.
Dimensions for multifunction printer (unpackaged)
Printer model Height Height with tray installed Width Depth Weight
CX310 470.3 mm (18.44 in.) Not applicable 444.0 mm (17.48 in.) 558.1 mm (21.99 in.) 27.4 kg (60.25 lb)
CX410 470.3 mm (18.44 in.) 600.3 mm (18.44 in.) 444.0 mm (17.48 in.) 558.1 mm (21.99 in.) 27.4 kg (60.25 lb)
CX510 470.3 mm (18.44 in.) 600.3 mm (18.44 in.) 444.0 mm (17.48 in.) 559.1 mm (23.2 in.) 28.2 kg (62.0 lb)
Dimensions for input options
Option Height Width Depth Weight
650‑sheet duo tray 133 mm (5.2 in.) 423.9 mm (16.7 in.) 416.4 mm (16.4 in.) 4.2 kg (9.3 lb)
550‑sheet tray 133 mm (5.2 in.) 423.9 mm (16.7 in.) 416.4 mm (16.4 in.) 4.2 kg (9.3 lb)
Clearance requirements
Note: These clearance values are for the most compact operating configuration of the product. Additional clearance
(especially from the front) may be needed to utilize the multipurpose feeder, clear paper misfeed, lift the scanner lid (for
MFPs only), or replace toner and imaging unit.
Printer specifications 18
