Notes:
You can select alerts for toner cartridges, imaging kit, maintenance kit, and waste toner bottle.
All alerts can be set for nearly low, low, and very low supply conditions. Not all alerts can be set for the
endoflife supply condition. Email alert is available for all supply conditions.
The percentage of estimated remaining supply that prompts the alert can be set on some supplies for some
supply conditions.
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears as four
sets of numbers separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Settings > Print Settings > Supply Notifications.
3 From the dropdown menu for each supply, select one of the following notification options:
Notification Description
Off The normal printer behavior for all supplies occurs.
Email Only The printer generates an e-mail when the supply condition is reached. The status of the
supply appears on the menus page and status page.
Warning The printer shows the warning message and generates an email about the status of the
supply. The printer does not stop when the supply condition is reached.
Continuable Stop
1
The printer stops processing jobs when the supply condition is reached. The user needs to
press a button to continue printing.
Non Continuable Stop
1,2
The printer stops when the supply condition is reached. The supply must be replaced to
continue printing.
1
The printer generates an e-mail about the status of the supply when supply notification is enabled.
2
The printer stops when some supplies become empty to prevent damage.
4 Click Submit.
Copying printer settings to other printers
Note: This feature is available only in network printers.
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears as four
sets of numbers separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click the Copy Printer Settings.
3 To change the language, select a language from the drop-down menu, and then click Click here to submit language.
4 Click Printer Settings.
Managing the printer 117

Table of Contents

Other manuals for Lexmark CS310n

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS310n and is the answer not in the manual?

Lexmark CS310n Specifications

General IconGeneral
ColorYes
Duplex printingNo
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)10 s
Time to first page (color, normal)11 s
Print speed (black, normal quality, A4/US Letter)23 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originChina
Maximum duty cycle60000 pages per month
Recommended duty cycle500 - 5000 pages per month
Number of print cartridges5
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Supported network protocols (IPv4)TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)TCP/IP IPv6, TCP, UDP
Maximum internal memory2304 MB
Sound power level (standby)16 dB
Sound pressure level (printing)48 dB
Total input capacity251 sheets
Total output capacity125 sheets
Maximum input capacity901 sheets
Total number of input trays1
Maximum number of input trays3
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supportedFedora 14, Fedora 15, RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (printing)- W
Package depth495 mm
Package width595 mm
Package height402 mm
Package weight23400 g
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
DisplayLCD
Product colorBlack, Grey
Weight and Dimensions IconWeight and Dimensions
Depth407 mm
Width442 mm
Height291 mm
