Note: When Jam Recovery is set to On or Auto, the printer reprints jammed pages. However, Auto does not
guarantee that the page will print.
7
5
6
3
2
4
1
Jam location Message on the display What to do
1 Standard bin Jam, standard bin [203.xx] Remove the jammed paper.
2 Fuser Jam, fuser. Open front
door. [202.xx]
Open the front door, pull the tab and hold the fuser cover
down, and then remove the jammed paper.
3 Front door Jam, front door [20y.xx] Open the front door, and then remove the jammed paper.
4 Duplex Jam, duplex area. Open front
door. [23y.xx]
Open the front door, and then remove the jammed paper.
5 Tray [x] Jam, tray [x] [24y.xx] Pull the indicated tray out, and then remove the jammed
paper.
6 Manual feeder Jam, manual feeder [251.xx] Remove the jammed paper.
7 Multipurpose feeder Jam, MP feeder [250.xx] Push the paper release lever to lift the paper rollers, and
then remove the jammed paper.
Clearing jams 121
