Turn off the printer, wait for about 10 seconds, and then turn the printer back on.
Update the network firmware in the printer or the print server. For more information, visit the Lexmark Web site
at
http://support.lexmark.com.
NonLexmark [color] [supply type], see User’s Guide [33.xy]
Note: The supply type can be toner cartridge or imaging kit.
The printer has detected a nonLexmark supply or part installed in the printer.
Your Lexmark printer is designed to function best with genuine Lexmark supplies and parts. Use of third-party supplies
or parts may affect the performance, reliability, or life of the printer and its imaging components.
All life indicators are designed to function with Lexmark supplies and parts, and may deliver unpredictable results if
third-party supplies or parts are used. Imaging component usage beyond the intended life may damage your Lexmark
printer or associated components.
Warning—Potential Damage: Use of third-party supplies or parts can affect warranty coverage. Damage caused by
the use of third-party supplies or parts may not be covered by the warranty.
To accept any and all of these risks, and to proceed with the use of non-genuine supplies or parts in your printer,
press
and on the printer control panel simultaneously for 15 seconds to clear the message and continue
printing.
If you do not wish to accept these risks, then remove the third-party supply or part from your printer, and then install
a genuine Lexmark supply or part.
Note: For the list of supported supplies, see the “Ordering supplies” section of the User's Guide or visit
www.lexmark.com.
Paper too short [34]
Try one or more of the following:
Load the correct size of paper in the tray.
From the printer control panel, press to clear the message and print using a different tray.
Check the tray length and width guides and make sure the paper is loaded properly in the tray.
Make sure the correct paper size and type are specified in Print Properties or in the Print dialog.
Make sure the paper size and type settings are specified in the Paper menu on the printer control panel.
Make sure the paper size is correctly set. For example, if the Multipurpose Feeder Size is set to Universal, then make
sure the paper is large enough for the data being printed.
Cancel the print job.
Printer restart. Check last job.
Press on the printer control panel to clear the message and continue printing.
For more information, visit
http://support.lexmark.com or contact customer support.
Troubleshooting 135

Table of Contents

Other manuals for Lexmark CS310n

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS310n and is the answer not in the manual?

Lexmark CS310n Specifications

General IconGeneral
ColorYes
Duplex printingNo
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)10 s
Time to first page (color, normal)11 s
Print speed (black, normal quality, A4/US Letter)23 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originChina
Maximum duty cycle60000 pages per month
Recommended duty cycle500 - 5000 pages per month
Number of print cartridges5
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Supported network protocols (IPv4)TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)TCP/IP IPv6, TCP, UDP
Maximum internal memory2304 MB
Sound power level (standby)16 dB
Sound pressure level (printing)48 dB
Total input capacity251 sheets
Total output capacity125 sheets
Maximum input capacity901 sheets
Total number of input trays1
Maximum number of input trays3
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supportedFedora 14, Fedora 15, RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (printing)- W
Package depth495 mm
Package width595 mm
Package height402 mm
Package weight23400 g
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
DisplayLCD
Product colorBlack, Grey
Weight and Dimensions IconWeight and Dimensions
Depth407 mm
Width442 mm
Height291 mm
