Lexmark CS310n User Manual

Use To
Color Samples
sRGB Display
sRGB Vivid
Display—True Black
Vivid
Off—RGB
US CMYK
Euro CMYK
Vivid CMYK
Off—CMYK
Print sample pages for each of the RGB and CMYK color conversion tables used in the
printer.
Notes:
• Selecting any setting prints the sample.
• Color samples consist of a series of colored boxes along with the RGB or CMYK
combination that creates the color observed. These pages can be used to help
decide which combinations to use to get the printed output you want.
• To access a complete list of color sample pages using the Embedded Web Server,
type the network printer IP address in the Web browser address field.
Manual Color
RGB Image
RGB Text
RGB Graphics
Customize the RGB color conversions.
Select from the following options:
Vivid
sRGB Display
Display—True Black
sRGB Vivid
Off
Notes:
• sRGB Display is the factory default setting for RGB Image. This applies a color
conversion table to an output that matches the colors displayed on a computer
monitor.
• sRGB Vivid is the factory default setting for RGB Text and RGB Graphics. This
applies a color table that increases saturation. This is preferred for business
graphics and text.
• Vivid applies a color conversion table that produces brighter, more saturated
colors.
• “Display—True Black” applies a color conversion table that uses only black toner
for neutral gray colors.
• Off turns off color conversion.
Manual Color (continued)
CMYK Image
CMYK Text
CMYK Graphics
Customize the CMYK color conversions.
Select from the following options:
US CMYK
Euro CMYK
Vivid CMYK
Off
Notes:
• US CMYK is the factory default setting. This applies a color conversion table that
tries to produce output that matches SWOP color output.
• Euro CMYK is the international factory default setting. This applies a color
conversion table that tries to produce output that matches Euroscale color
output.
• Vivid CMYK increases color saturation for the US conversion table.
• Off turns off color conversion.
Understanding the printer menus 77

Lexmark CS310n Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	23 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	60000 pages per month
Recommended duty cycle	500 - 5000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Maximum internal memory	2304 MB
Sound power level (standby)	16 dB
Sound pressure level (printing)	48 dB
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	901 sheets
Total number of input trays	1
Maximum number of input trays	3
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	Fedora 14, Fedora 15, RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (printing)	- W
Package depth	495 mm
Package width	595 mm
Package height	402 mm
Package weight	23400 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Display	LCD
Product color	Black, Grey

Weight and Dimensions

Depth	407 mm
Width	442 mm
Height	291 mm
