6 Remove the metal brackets and the locking clip that secure the 2 x 500‑ or 2500‑sheet tray to the printer.
• Front
• Rear
7 Close the trays.
8 Using the side handles, remove the printer from the 2 x 500‑ or 2500‑sheet tray.
CAUTION—POTENTIAL INJURY: If the printer weight is greater than 18 kg (40 lb), then it requires
two or more trained personnel to lift it safely.
Upgrading and migrating 138
