Lexmark CS921 User Manual

Lexmark CS921
169 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #20 background imageLoading...
Page #20 background image
Adjusting the default headphones volume
Headphones volume will reset to default value after the session is logged out, when the printer wakes from
Sleep or Hibernate mode, or after a poweron reset.
1 From the control panel, select Settings > Device > Accessibility > Headphone Volume.
2 Select the volume.
Enabling spoken passwords or personal identification
numbers
1 From the home screen, select Settings > Device > Accessibility > Speak Passwords/PINs.
2 Enable the setting.
Navigating the screen using gestures
Notes:
The gestures are applicable only when Voice Guidance is activated.
A physical keyboard is required for typing characters and adjusting certain settings.
Gesture Function
Doubletap Select an option or item on the screen.
Tripletap Zoom in or zoom out text and images.
Swipe right or swipe down Move to the next item on the screen.
Swipe left or swipe up Move to the previous item on the screen.
Pan Access parts of the zoomed image that are beyond the limits of the screen.
Note: This gesture requires the use of two
fingers
to drag across a zoomed
image.
Swipe up then left Exit an application and return to the home screen.
Swipe down then left
Cancel a job.
Go back to the previous setting.
Exit the screen that appears without changing any setting or value.
Swipe up then down Repeat a spoken prompt.
Using the keyboard on the display
Do one or more of the following:
Drag a
finger
over the key to announce the character.
Lift the
finger
to enter or type the character in the
field.
Press Backspace to delete characters.
To hear the content in the input field, press Tab, and then press Shift + Tab.
Setting up and using the accessibility features 20

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS921 and is the answer not in the manual?

Lexmark CS921 Specifications

General IconGeneral
DisplayLCD
Control typeTouch
CertificationICES-003 A, BSMI A, VCCI A, FCC A, NOM-032, UL, cUL, NOM, US FDA/CDRH, IEC 60825-1, CB Report, ISO-532B, CE (EU) DoC, EFTA (CE), KC logo, CCC, C-tick DoC, EuP, CECP, CEL, EC 1275/2008, ECMA-370, TED, SII, TER, SABS, UL-AR, GS Mark, Green Dot, ISO-9296, COC, CCD-035 EcoLogo, Green Mark, EPEAT
Product colorBlack, White
Display diagonal4.3 \
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Printing colorsCyan, Magenta, Yellow
Country of originChina
Maximum duty cycle150000 pages per month
Recommended duty cycle4000 - 20000 pages per month
Number of print cartridges3
Page description languagesPCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3, XPS
Average cartridge yield (CMY)11500 pages
Average cartridge yield (black)18500 pages
Power consumption (ready)140 W
Power consumption (standby)2.2 W
Power consumption (printing)575 W
Energy Star Typical Electricity Consumption (TEC)2.3 kWh/week
Processor cores4
Noise level (idle)25 dB
Maximum internal memory3072 MB
Sound pressure level (printing)51 dB
Sound pressure level (duplex printing)53 dB
Sustainability certificatesBlue Angel, ENERGY STAR
Paper input typePaper tray
Total input capacity1150 sheets
Total output capacity250 sheets
Maximum input capacity6650 sheets
Paper tray 2 input capacity500 sheets
Total number of input trays2
Maximum number of input trays5
Multi-Purpose tray input capacity150 sheets
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supportedDebian 7.0, Debian 8.0, Fedora 21, Fedora 22, Linpus Lite 2.1, Linux Mint 13, Linux Mint 17, Linux Mint 17.1, Linux Mint 17.2, Linux Mint Debian Edition 2 (LMDE 2), Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, SUSE Linux Enterprise Desktop 10, SUSE Linux Enterprise Desktop 11, SUSE Linux Enterprise Desktop 12, SuSE Linux 10, SuSE Linux 11, SuSE Linux 12.0, Ubuntu 12.04, Ubuntu 14.04, Ubuntu 15.04, openSUSE 13.1, openSUSE 13.2, openSUSE Tumbleweed
Other operating systems supportedIBM AIX 6.1, IBM AIX 7.1
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesBanner, Card stock, Envelopes, Labels, Plain paper
Paper tray media weight60 - 256 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Super Tabloid (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A3, A4, A5, A6
Maximum ISO A-series paper sizeA3
Operating altitude0 - 2500 m
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)15 - 85 %
Supported protocolsTCP, UDP, LPR/LPD, FTP, TFTP, Telnet, IPP 1.0, 1.1, 2.0
Package depth911 mm
Package width758 mm
Package height1057 mm
Package weight103000 g
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithmsIPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, TTLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfacesEthernet, USB 2.0
Optional connectivityFiber, Parallel, Serial (RS-232), Wireless LAN
Weight and Dimensions IconWeight and Dimensions
Depth693 mm
Width615 mm
Height780 mm
