Menu item Description
Font Priority
Resident*
Flash/Disk
Establish the font search order.
Notes:
• Resident sets the printer to search its memory for the requested font
before searching the flash memory or printer hard disk.
• Flash/Disk sets the printer to search the flash memory or printer hard
disk for the requested font before searching the printer memory.
• This menu item appears only when a flash memory or hard disk is
installed.
Wait Timeout
O
On* (40 seconds)
Enable the printer to wait for more data before canceling a print job.
Note: An asterisk (*) next to a value indicates the factory default setting.
PCL
Menu item Description
Font Source
Resident*
Disk
Flash
All
Choose the source which contains the default font selection.
Notes:
• Flash and Disk appear only when a flash memory or hard disk is
installed.
• For Flash and Disk to appear, make sure that they are not read‑ or
write‑protected.
Font Name
Courier*
Select a font from the specified font source.
Symbol Set
10U PC‑8*
Specify the symbol set for each font name.
Note: A symbol set is a set of alphabetic and numeric characters,
punctuation, and special symbols. Symbol sets support the dierent
languages or specific programs such as math symbols for scientific text.
Pitch
0.08–100 (10*)
Specify the pitch for fixed or monospaced fonts.
Note: Pitch refers to the number of fixed‑space characters in a horizontal
inch of type.
Orientation
Portrait*
Landscape
Specify the orientation of text and graphics on the page.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 64

Lexmark CS923 Specifications

General

Control type	Touch
Certification	ICES-003 A, BSMI A, VCCI A, FCC A, NOM-032, UL, cUL, NOM, US FDA/CDRH, IEC 60825-1, CB Report, ISO-532B, CE (EU) DoC, EFTA (CE), KC logo, CCC, C-tick DoC, EuP, CECP, CEL, EC 1275/2008, ECMA-370, TED, SII, TER, SABS, UL-AR, GS Mark, Green Dot, ISO-9296, COC, CCD-035 EcoLogo, Green Mark, EPEAT
Product color	Black, White
Display diagonal	4.3 \
Print technology	Laser
Duplex printing mode	Auto
Warm-up time (from sleep mode)	5.1 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Cyan, Magenta, Yellow
Maximum duty cycle	250000 pages per month
Number of print cartridges	3
Page description languages	PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3, XPS
Average cartridge yield (CMY)	11500 pages
Average cartridge yield (black)	18500 pages
Power consumption (ready)	200 W
Power consumption (standby)	2.2 W
Power consumption (printing)	11500 W
Energy Star Typical Electricity Consumption (TEC)	4.5 kWh/week
Processor cores	4
Noise level (idle)	26 dB
Processor frequency	1200 MHz
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	54 dB
Sustainability certificates	Blue Angel, ENERGY STAR
Paper input type	Paper tray
Total output capacity	250 sheets
Maximum input capacity	6650 sheets
Paper tray 2 input capacity	500 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Debian 7.0, Debian 8.0, Fedora 21, Fedora 22, Linpus Lite 2.1, Linux Mint 13, Linux Mint 17, Linux Mint 17.1, Linux Mint 17.2, Linux Mint Debian Edition 2 (LMDE 2), Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, SUSE Linux Enterprise Desktop 10, SUSE Linux Enterprise Desktop 11, SUSE Linux Enterprise Desktop 12, SuSE Linux 10, SuSE Linux 11, SuSE Linux 12.0, Ubuntu 12.04, Ubuntu 15.04, openSUSE 13.1, openSUSE 13.2, openSUSE Tumbleweed
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Banner, Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 256 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Super Tabloid (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Maximum ISO A-series paper size	A3
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	15 - 85 %
Supported protocols	TCP, UDP, LPR/LPD, FTP, TFTP, Telnet, IPP 1.0, 1.1, 2.0
Package depth	911 mm
Package width	758 mm
Package height	1057 mm
Package weight	103000 g
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Cables included	AC
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Fiber, Parallel, Serial (RS-232), Wireless LAN

Weight and Dimensions

Depth	693 mm
Width	615 mm
Height	780 mm
