Lexmark CX310dn - GL;2 Commands

= Supported
X = Not supported
Printer model
Command Function CS310, CS410, CS510 CX310, CX410, CX510
ESC
*v#N
Source Transparency Mode
ESC
*v#O
Pattern Transparency Mode
ESC
*v#S
Foreground Color
ESC
*v#T
Select Current Pattern
ESC
*v#W[data]
Configure Image Data
ESC
*i#W[data]
Viewing Illuminant XX
ESC
9
Clear Horizontal Margins
ESC
=
Half Line-Feed
ESC
%#A
Enter HP PCL 5 Mode
ESC
%#B
Enter HP‑GL/2 Mode
Note: The values ‑1, 2, and 3 are not
supported by any of the printers
included in this document.
ESC
%‑12345X
Universal Exit Language (UEL) /
Start of PJL
GL/2 commands
= Supported
X = Not supported
Printer model
Command Function CS310, CS410, CS510 CX310, CX410, CX510
AA Arc Absolute
AC Anchor Corner
AD Define Alternate Font
AR Arc Relative
AT Arc Absolute Three Point
BR Bezier Relative
BZ Bezier Absolute
CF Character Fill
CI Circle
CO Comment
CP Character Plot
CR Color Range
Appendix A: PCL support 26
