10
Install memory cards
Removing the system board shield Use a No. 2 Phillips screwdriver to
remove the system board shield.
1 Remove the top screw and set it
aside.
2 Loosen the bottom three screws,
but do not remove them.
3 Slide the system board shield
along the top and bottom grooves
and set it aside.
Installing a memory card Follow the instructions in this section to
install a printer memory card.
The system board has two connectors for
optional memory cards. You can install a
card in either connector.
