Lexmark MS317 User Manual

• Load letterhead faceup with the top edge entering the printer first. For two‑sided (duplex) printing, load
letterhead facedown with the bottom edge entering the printer
first.
• Load envelopes with the
flap
on the left side facedown.
Warning—Potential Damage: Never use envelopes with stamps, clasps, snaps, windows, coated
linings, or self‑stick adhesives. These envelopes may severely damage the printer.
5 From the printer control panel, set the paper size and paper type in the Paper menu to match the paper or
specialty media loaded in the multipurpose feeder.
Linking and unlinking trays
The printer links trays when the
specified
paper size and type are the same. When a linked tray becomes empty,
paper feeds from the next linked tray. To prevent trays from linking, assign a unique custom paper type name.
MS312 and MS317 tray linking
Linking and unlinking trays
Using the Embedded Web Server
1 Open a Web browser, and then type the printer IP address in the address
field.
Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears
as four sets of numbers separated by periods, such as 123.123.123.123.
Loading paper and specialty media 41

Lexmark MS317 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 50, 000 pages
Standard Connectivity	USB 2.0, Ethernet
Standard Memory	128 MB
Processor	800 MHz
Duplex Printing	Manual
Input Capacity	250 sheets
Output Capacity	Up to 150 sheets
First Page Out Time	6.5 seconds
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Linux, Mac
