Page #31 background image
Understanding the colors of the Sleep button and
indicator lights
The colors of the Sleep button and indicator lights on the printer control panel signify a certain printer status
or condition.
Indicator light Printer status
O The printer is o or in Hibernate mode.
Blinking green The printer is warming up, processing data, or printing.
Solid green The printer is on, but idle.
Blinking red The printer requires user intervention.
Sleep button light Printer status
O The printer is o, idle or in Ready state.
Solid amber The printer is in Sleep mode.
Blinking amber The printer is entering or waking from Hibernate mode.
Blinking amber for 0.1 second, then goes
completely o for 1.9 seconds in a slow,
pulsing pattern
The printer is in Hibernate mode.
Accessing the Embedded Web Server
The Embedded Web Server is the printer Web page that lets you view and remotely
configure
printer settings
even when you are not physically near the printer.
1 Obtain the printer IP address:
From the printer control panel home screen
From the TCP/IP section in the Network/Ports menu
By printing a network setup page or menu settings page, and then finding the TCP/IP section
Note: An IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.
2 Open a Web browser, and then type the printer IP address in the address field.
3 Press Enter.
Note: If you are using a proxy server, then temporarily disable it to load the Web page correctly.
Using MS315, MS415, and MS417 31

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MS317dn and is the answer not in the manual?

Lexmark MS317dn Specifications

General IconGeneral
Envelopes sizes7 3/4, 9, 10, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 90 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Finishing optionNo
Authentication method802.1x
Cables includedAC
Cartridge(s) includedYes
Included cartridge capacity (black)1500 pages
DisplayLCD
CertificationENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, Customs Union EAC, SII, TER
Product colorGray
Display number of lines2 lines
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Duplex print speed (black, normal quality, A4/US Letter)14 ppm
Printing colorsBlack
Country of originChina
Maximum duty cycle50000 pages per month
Recommended duty cycle500 - 2500 pages per month
Number of print cartridges-
Page description languagesMicrosoft XPS, PCL 5e, PCL 6, PPDS, PostScript 3
Internal memory128 MB
Processor cores2
Noise level (idle)15 dB
Processor frequency800 MHz
Sound pressure level (printing)53 dB
Sound pressure level (duplex printing)52 dB
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity850 sheets
Maximum number of input trays3
Multi-Purpose tray input capacity50 sheets
Cabling technology10/100Base-T(X)
Security algorithmsIPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates10, 100 Mbit/s
Supported network protocols (IPv4)TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)TCP/IP IPv6, TCP, UDP
USB connectorUSB Type-B
Standard interfacesEthernet, Parallel, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantity1
Package depth472 mm
Package width432 mm
Package height380 mm
Package weight15800 g
Power consumption (off)0.5 W
Power consumption (ready)7 W
Power consumption (printing)520 W
Energy Star Typical Electricity Consumption (TEC)1.6 kWh/week
Sustainability certificatesBlue Angel, ENERGY STAR
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth382 mm
Width399 mm
Height263 mm
Weight14000 g
