Lexmark MS317dn User Manual

MS315, MS415, and MS417 printer management
Checking the virtual display
1 Open a Web browser, and then type the printer IP address in the address
field.
Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears
as four sets of numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Check the virtual display that appears at the top left corner of the screen.
The virtual display works as an actual display would work on a printer control panel.
Modifying
confidential
print settings
Note: This feature is available only in network printers or printers connected to print servers.
1 Open a Web browser, and then type the printer IP address in the address
field.
Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears
as four sets of numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Settings tab > Security >
Confidential
Print Setup.
3 Modify the settings:
• Set a maximum number of PIN entry attempts. When a user exceeds a
specific
number of PIN entry
attempts, all of the jobs for that user are deleted.
• Set an expiration time for
confidential
print jobs. When a user has not printed the jobs within the
specified
time, all of the jobs for that user are deleted.
4 Save the modified settings.
Saving energy
Using Eco‑mode
Use Eco‑Mode to quickly select one or more ways to reduce your printer's environmental impact.
1 From the printer control panel, navigate to:
> Settings > Settings > > General Settings > > Eco‑Mode > > select the setting you want
Managing the printer 66

Lexmark MS317dn Specifications

General

Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Finishing option	No
Authentication method	802.1x
Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	1500 pages
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, Customs Union EAC, SII, TER
Product color	Gray
Display number of lines	2 lines
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Printing colors	Black
Country of origin	China
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 2500 pages per month
Number of print cartridges	-
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PPDS, PostScript 3
Internal memory	128 MB
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Cabling technology	10/100Base-T(X)
Security algorithms	IPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
USB connector	USB Type-B
Standard interfaces	Ethernet, Parallel, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	15800 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	520 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
Weight	14000 g
