Lexmark MS415dn User Manual

Using MS315, MS415, and MS417
Using the control panel
Use the To
1 Display View the printer status and messages.
Set up and operate the printer.
2 Left arrow button Scroll to the left.
3 Select button Select menu options.
Save settings.
4 Up arrow button Scroll up.
5 Right arrow button Scroll to the right.
6 Keypad Enter numbers, letters, or symbols.
7 Sleep button Enable Sleep mode or Hibernate mode.
The following actions wake the printer from Sleep mode:
• Pressing any hard button
• Sending a print job from the computer
• Performing a power‑on reset using the main power switch
The following actions wake the printer from Hibernate mode:
• Pressing the Sleep button until the printer wakes
• Performing a power‑on reset using the main power switch
8 Stop or cancel button Stop all printer activities.
9 Back button Return to the previous screen.
10 Down arrow button Scroll down.
11 Home button Go to the home screen.
12 Indicator light Check the status of the printer.
Using MS315, MS415, and MS417 30

Lexmark MS415dn Specifications

General

Print Technology	Laser
Print Speed	Up to 40 ppm
Print Resolution	1200 x 1200 dpi
Processor Speed	800 MHz
Duplex Printing	Yes
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	256 MB
Input Capacity	250 sheets
Connectivity	USB, Ethernet
Dimensions	10.3 x 15.7 x 15.0 inches
