Page #212 background imageLoading...
Page #212 background image
Use To
PCL SmartSwitch
On
Off
Set the printer to automatically switch to PCL emulation when a print job received
through a serial port requires it, regardless of the default printer language.
Notes:
On is the factory default setting.
When set to Off, the printer does not examine incoming data. The printer uses
PostScript emulation if PS SmartSwitch is set to On. It uses the default printer
language specified in the Setup menu if PS SmartSwitch is set to Off.
PS SmartSwitch
On
Off
Set the printer to automatically switch to PS emulation when a print job received
through a serial port requires it, regardless of the default printer language.
Notes:
On is the factory default setting.
When set to Off, the printer does not examine incoming data. The printer uses
PCL emulation if PCL SmartSwitch is set to On. It uses the default printer
language specified in the Setup menu if PCL SmartSwitch is set to Off.
NPA Mode
On
Off
Auto
Set the printer to perform the special processing required for bidirectional
communication following the conventions defined by the NPA protocol.
Notes:
Auto is the factory default setting.
Changing this setting from the printer control panel and then exiting the
menus causes the printer to restart. The menu selection is then updated.
Parallel Buffer
Disabled
Auto
3K to [maximum size allowed]
Set the size of the parallel input buffer.
Notes:
Auto is the factory default setting.
Disabled turns off job buffering. Any print jobs already buffered on the printer
hard disk are printed before normal processing resumes.
The parallel buffer size setting can be changed in 1KB increments.
The maximum size allowed depends on the amount of memory in the printer,
the size of the other link buffers, and whether Resource Save is set to On or
Off.
To increase the maximum size range for the Parallel Buffer, disable or reduce
the size of the USB, serial, and network buffers.
Changing this setting from the printer control panel and then exiting the
menus causes the printer to restart. The menu selection is then updated.
Job Buffering
Off
On
Auto
Temporarily store print jobs on the printer hard disk before printing.
Notes:
Off is the factory default setting.
On buffers print jobs on the printer hard disk.
Auto buffers print jobs only if the printer is busy processing data from another
input port.
Changing this setting from the printer control panel and then exiting the
menus causes the printer to restart. The menu selection is then updated.
Understanding the printer menus 212

Table of Contents

Other manuals for Lexmark MS811dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MS811dn and is the answer not in the manual?

Lexmark MS811dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)4.4 s
Print speed (black, normal quality, A4/US Letter)60 ppm
Duplex print speed (black, normal quality, A4/US Letter)36 ppm
Security algorithmsLEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Printing colorsBlack
Country of originChina
Maximum duty cycle275000 pages per month
Recommended duty cycle5000 - 30000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XML
Internal memory512 MB
Processor frequency800 MHz
Maximum internal memory2560 MB
Sound pressure level (printing)58 dB
Sound pressure level (quiet mode)53 dB
Total input capacity650 sheets
Total output capacity550 sheets
Maximum input capacity4400 sheets
Total number of input trays2
Maximum number of input trays6
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesUSB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supportedFedora 14, Fedora 15, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)770 W
Package weight27430 g
Networking featuresGigabit Ethernet
Sustainability certificatesENERGY STAR
DisplayLCD
CertificationCSA, ICES, BSMI, CNS, VCCI, US, FDA, FCC, IEC, CE, GS, TUV, SEMKO, SMA, CCC, CISPIR, ECMA, TED
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Weight and Dimensions IconWeight and Dimensions
Weight23660 g
Dimensions (WxDxH)425 x 419 x 510 mm
