2 Remove the jammed paper.
3 Open door C to remove any paper fragments.
Note: Make sure that door C does not hit any cable attached to
the printer.
4 Close door C.
5 Flex the sheets back and forth to loosen them, and then fan them.
Do not fold or crease the paper. Straighten the edges on a level
surface.
6 Reload the paper.
[x]‑page jam, open door C and clear all
jammed paper. [2yy.xx]
1 Open door C. Make sure that it does not hit any cable attached to
the printer.
2 Remove the jammed paper from any of the following locations:
Note: Make sure that all paper fragments are removed.
CAUTION—HOT SURFACE: The inside of the printer might
be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching it.
• Fuser area
• Below the fuser area
• Duplex area
• Above the duplex area
3 Open the standard trays, and then locate the jammed paper.
4 Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
7
