Lexmark Optra T User Manual

PCL
2-48
Table 2-29: User-Defined Pattern
Command / Parameters Function / Result
ESC
*c#W[data]
# = number of data bytes
User-Defined Pattern
Downloads binary pattern data.
ESC
*p#R
0 Rotate with print (Default)
1Fixed
Set Pattern Reference Point
Sets pattern reference point to the current cursor position for user-
defined patterns.
Note: Default pattern reference point is the upper left corner of logical
page.
ESC
*c#Q
0 Delete all patterns (temporary and
permanent)
1 Delete all temporary patterns
2 Delete pattern (last ID specified)
4 Make pattern of last ID # temporary
5 Make pattern of last ID # permanent
Pattern Control
Manages use of user-defined patterns.
Note: UseAreaFillIDcommand(
ESC
*c#G) to set ID.
Table 2-30: Rectangular Area Fill Graphics
Command / Parameters Function / Result
ESC
*c#H
# = Number of Decipoints (0 - 32767)
(1 Decipoint = 1/720 inch)
Default = 0, valid to 4 decimal places
Horizontal Rectangle Size (in Decipoints)
Specifies the rectangle width in decipoints.
ESC
*c#A
# = Number of PCL Units (0 - 32767)
Default = 0
Horizontal Rectangle Size (in PCL Units)
Specifies the rectangle width in PCL units.
Note: Size of PCL Units is set by Unit-of-Measure command.
ESC
*c#V
# = Number of Decipoints (0 - 32767)
(1 Decipoint = 1/720 inch)
Default = 0, valid to 4 decimal places
Vertical Rectangle Size (in Decipoints)
Specifies the rectangle height in decipoints.
ESC
*c#B
# = Number of PCL Units (0 - 32767)
Default = 0
Vertical Rectangle Size (in PCL Units)
Specifies the rectangle height in PCL units.
Note: Size of PCL Units is set by Unit-of-Measure command.
