PCL
2-50
Table 2-31: Raster Graphics
Command / Parameters Function / Result
ESC
*t#R
75 75 dpi
100 100 dpi
150 150 dpi
200 200 dpi
300 300 dpi
600 600 dpi
1200 1200 dpi
Raster Resolution
Note: 200 dpi is only supported when the printer is operating in
600 dpi or 1200 dpi mode.
ESC
*r#F
0 Rotatewithprint
3 Fixed (Default)
Raster Graphics Presentation
Sets the Raster Image Orientation in relation to the logical page.
ESC
*r#S
# = Number of Input Pixels
Raster Width (Source)
Sets width of clip window for raster graphics.
ESC
*r#T
# = Number of Raster Lines
Raster Height (Source)
Sets height of clip window for raster graphics.
ESC
*r#A
0 Left Graphics Margin at 0 (Default)
1 Current Cursor Position
2 At logical left page limit with scaling
On
3 At current cursor position with
scaling On
Start Raster Graphics
Sets the left margin for raster graphics.
ESC
*b#V[data]
# = Number of Data Bytes
Transfer Raster Data by Plane
This command is used when the raster data is encoded by plane as
specified by the Simple Color command or the Configure Image
Data command. The command sends each plane in the row except
the last.
ESC
*b#Y
# = Number of Raster Lines
Y Offset
Moves cursor position down by the specified number of raster lines.
