Use To
12 Color
Switch to color mode.
13 Black
Switch to blackandwhite mode.
14 Start
Start a job, depending on which mode is selected.
15 Cancel
Cancel a print, copy, scan, or fax job in progress.
Clear current settings or error messages, and return to previous settings.
16 WiFi indicator
Check the wireless status of your printer.
17 EcoMode
Change to Sleep mode after the printer is left idle for 10 minutes.
Reduce the screen brightness.
Using flash drives
Supported file types
.jpg, .jpeg, .jpe (Joint Photographic Experts Group)
.tiff, .tif (Tagged Image File Format)
Using a flash drive with the printer
Make sure the flash drive contains files that are supported by the printer. For more information, see
“Supported file types” on page 16.
1 Insert a flash drive into the USB port.
F
L
A
S
H
D
R
I
V
E
Notes:
The flash drive uses the same port that is used for a PictBridge camera cable.
An adapter may be necessary if your flash drive does not fit directly into the port.
Warning—Potential Damage: Do not touch any cables,
any network adapter, any connector, the memory
device, or the printer in the areas shown while actively
printing, reading, or writing from the memory device. A
loss of data can occur.
2 Follow the instructions or select from available options on the printer display.
Note: If the printer does not recognize the memory device, then remove and reinsert it.
About your printer 16

Table of Contents

Other manuals for Lexmark S415

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark S415 and is the answer not in the manual?

Lexmark S415 Specifications

General IconGeneral
DisplayLCD
Modem speed33.6 Kbit/s
Color faxingYes
Network readyNo
Dimensions (WxDxH)432 x 366 x 268 mm
All-in-one functionsCopy, Fax, Print, Scan
Connectivity technologyWired
Color all-in-one functionscopy, fax, print, scan
Compatible operating systemsMicrosoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Microsoft Windows 7 x64 Microsoft Windows Server 2008 R2
Print technologyInkjet
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)30 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle7000 pages per month
Maximum copy resolution- DPI
Copy speed (black, normal quality, A4)25 cpm
Copy speed (color, normal quality, A4)21 cpm
Scanner typeADF scanner
Maximum scan area216 x 356 mm
Optical scanning resolution1200 x 1200 DPI
Total input capacity100 sheets
Total output capacity25 sheets
Envelopes sizes6 3/4, B5, C6, DL
Maximum print size-
Paper tray media typesBanner, Card stock, Envelopes, Iron-On Transfers, Plain paper, Transparencies
Non-ISO print media sizes2L, L
ISO A-series sizes (A0...A9)A4, A5, A6
Maximum ISO A-series paper sizeA4
Display diagonal2.4 \
Market positioningHome & office
Standard interfacesUSB 2.0, Wireless LAN
Wi-Fi standards802.11b, 802.11g
Processor frequency330 MHz
Sound power level (standby)16 dB
Sound pressure level (copying)48 dB
Sound pressure level (printing)46 dB
Sound pressure level (scanning)45 dB
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (average operating)32 W
Package weight10270 g
Sustainability certificatesENERGY STAR
CertificationEnergy Star, CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
