Arguments for PDF417 bar code symbology
88
Arguments for PDF417 bar code symbology
Key Type
Default
Value
Definition
/Symbology Name Required
Identifies the bar code symbology (/PDF417).
/Type integer Required
If /Rows is set to 0, then /Columns is set manually.
If /Rows is set to 1, then /Columns is determined by
/AspectRatio.
/Rows integer Required
If /Type is set to 0, then the number of symbol rows is set
manually. Valid values are 3 to 90. Any value outside this range
causes a RANGECHECK error.
/Columns integer Required
If /Type is set to 0, then the number of symbol columns is set
manually. Valid values are 1 to 30. Any value outside this range
causes a RANGECHECK error.
/AspectRatio real Required
If /Type is set to 1, then the alternate way of designing rows and
columns ratio is through height/width. Valid values are 0.1 to
10.0. Any value outside this range causes a value of 0.5 to be
used.
Example:
For a height-to-width ratio of 2/3, set /AspectRatio equal to
0.67.
/Units Optional
The value is 1/600 inch.
/ModuleWidth integer Required
Sets the module width in /Units. Specifies the X dimension
(smallest element width)
Example:
A value of 15 specifies an element width of 15/600 inch.
/Height integer Required
Specifies the bar height in terms of /ModuleWidth
Example:
When /ModuleWidth is set to 15, a value of 3 sets the bar height
to 45/600 inch.
