Lexmark X651DE User Manual

Diagnostic information 2-123
7462
Go Back
Previous
Next
Sensor (ADF media exit) static jam service check
2
Check the sensor (ADF document set) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch TBD
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
3
Check the sensor (2nd scan) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
document set).
Go to “Sensor
(ADF document
set) removal” on
page 4-78.
Replace the
connection.
4
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
removal” on
page 4-62.
Go to step 5.
Problem resolved.
5
Perform a print test using the ADF.
Does the problem remain?
Contact next
highest level of
tech support.
Problem resolved.
Use this procedure for the following jams:
• 294.00
1 Check the media path.
Is the media path free of media or media fragments?
Go to step 2. Remove any
media or media
fragments.
2
Check the sensor (ADF media exit) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Observe the line “sensor (ADF media exit)”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
Step Check Yes No

Lexmark X651DE Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Duplex print speed (black, normal quality, A4/US Letter)	29 ppm
Copy speed (black, normal quality, A4)	43 cpm
Total input capacity	650 sheets
Maximum input capacity	3200 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Dimensions (WxDxH)	548 x 611 x 755 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard input trays	2
Maximum internal memory	1.28 GB
Color all-in-one functions	scan, n
Compatible operating systems	Apple Mac OS X, Apple Mac OS 9.x, Linpus Linux Desktop 9.2, 9.3, Red Hat Enterprise Linux WS 3.0, 4.0, 5.0, SUSE Linux Enterprise Server 8.0, 9.0, 10.0, SUSE Linux Enterprise Desktop 10, openSUSE 10.2, 10.3, 11.0, Linspire Linux 6.0, Debian GNU/Linux 4.0, Red Flag Linux Desktop 5.0, 6.0, Ubuntu 7.10, Ubuntu 8.04 LTS, Microsoft Windows 2000, Microsoft Windows XP, Microsoft Windows Server 2003, Microsoft Windows XP x64, Microsoft Windows Server 2003, Microsoft Windows 2000 Server, Microsoft Windows Server 2003 x64, Microsoft Windows Vista, Microsoft Windows Vista x64, Microsoft Windows Server 2008, Microsoft Windows Server 2008 x64, Novell Open Enterprise Server, Netware + NDS, iPrint / Novell Distributed Print Services (NDPS), Novell NetWare 5.x, 6.x iPrint / Novell, Distributed Print Services (NDPS), Sun Solaris SPARC 8, 9, 10, Sun Solaris x86 10, HP-UX 11.11, 11.23, 11.31, IBM AIX 5.2, 5.3, 6.1, IBM iSeries / IBM AS/400 Systems + TCP/IP + OS/400 V3R1.
Sound power level (standby)	29 dB
Sound pressure level (copying)	55 dB
Sound pressure level (printing)	54 dB
Sound pressure level (scanning)	56 dB
Control type	Touch
Display diagonal	7 \
Market positioning	Business
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security algorithms	LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Maximum duty cycle	200000 pages per month
Page description languages	PCL 5e, PCL 6, PDF 1.6, PostScript 3, PPDS, xHTML
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR
Certification	Blue Angel (RAL-UZ-122), CE Class A, CB IEC 60950-1, IEC 60825-1, IEC 61000-3-2, IEC 61000-3-3, EN 55022 Class A, EN 55024, CISPR 22 Class A, IEC 60320, GS (TÜV), EN 60825-1, ACMA A-tick mark Class A, AS/NZS 60950-1, EK Mark, KCC MIC Mark, CCC Class A, UL AR, CS, TÜV Rh
