Lexmark X651DE - Sheet Media Tray Assembly Removal

To Next Page

To Previous Page

Repair information 4-173

7462

Go Back

250-sheet media tray assembly removal

Remove the 250-sheet media tray assembly from the 250-sheet option drawer assembly.

250-sheet option drawer assembly removal

Remove the 250-sheet media tray assembly from the 250-sheet option drawer assembly.
