Lexmark X651DE User Manual

Diagnostic aids 3-61
7462
Go Back
Previous
Next
System card assembly
The system card assembly controls printing operation based on the communication with the RIP controller and
optional peripherals. It also controls toner dispense, fuser control, sensor switch feedback, drive motors,
clutches and solenoids
Control
Printhead control
Rotation of printhead motor
The on/off control of the printhead motor is performed according to the mode of operation as shown below.
Determination of printhead ready
The printhead goes into ready state after the specified period passes since the reception of the printhead MPA
start signal and the SOS cycle exceeds the reference value.
Printhead reference value
Fuser control
Fuser control method
The on/off control of the main/sub heater lamps is performed based on the fuser control temperature. The fuser
transmits between the five states (warm up, ready, standby, print, and low power) depending on the heat roll
surface temperature or printer conditions.
The fuser temperature control starts when the fuser ready in the system card assembly is turned on after a
preset time period has passed from power on. If a failure occurs, the heater lamps are turned off, the fuser
ready is turned off, and then the fuser temperature control is stopped.
Fuser lamp on/off control
The thermistor detects the heat roll surface temperature (fuser temperature) to regulate the temperature at the
target control temperature by turning on or off the heater lamp.
Operation mode PRINTHEAD motor on/off
Standby mode Always off
Print mode Turns on upon receiving the signal from the controller,
and turns off after a preset time has passed from the
end of printing. Also turns off if a print command is not
received within 30 seconds from the reception of the
signal.
Sleep mode Always off
Printhead reference value Description
Ready reference value SOS signal interval (equivalent to 98% or more of the rated RPM of the
printhead motor)
Fail reference value SOS signal interval (less than 98% of the rated rpm of the printhead
motor)

Lexmark X651DE Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Duplex print speed (black, normal quality, A4/US Letter)	29 ppm
Copy speed (black, normal quality, A4)	43 cpm
Total input capacity	650 sheets
Maximum input capacity	3200 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Dimensions (WxDxH)	548 x 611 x 755 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard input trays	2
Maximum internal memory	1.28 GB
Color all-in-one functions	scan, n
Compatible operating systems	Apple Mac OS X, Apple Mac OS 9.x, Linpus Linux Desktop 9.2, 9.3, Red Hat Enterprise Linux WS 3.0, 4.0, 5.0, SUSE Linux Enterprise Server 8.0, 9.0, 10.0, SUSE Linux Enterprise Desktop 10, openSUSE 10.2, 10.3, 11.0, Linspire Linux 6.0, Debian GNU/Linux 4.0, Red Flag Linux Desktop 5.0, 6.0, Ubuntu 7.10, Ubuntu 8.04 LTS, Microsoft Windows 2000, Microsoft Windows XP, Microsoft Windows Server 2003, Microsoft Windows XP x64, Microsoft Windows Server 2003, Microsoft Windows 2000 Server, Microsoft Windows Server 2003 x64, Microsoft Windows Vista, Microsoft Windows Vista x64, Microsoft Windows Server 2008, Microsoft Windows Server 2008 x64, Novell Open Enterprise Server, Netware + NDS, iPrint / Novell Distributed Print Services (NDPS), Novell NetWare 5.x, 6.x iPrint / Novell, Distributed Print Services (NDPS), Sun Solaris SPARC 8, 9, 10, Sun Solaris x86 10, HP-UX 11.11, 11.23, 11.31, IBM AIX 5.2, 5.3, 6.1, IBM iSeries / IBM AS/400 Systems + TCP/IP + OS/400 V3R1.
Sound power level (standby)	29 dB
Sound pressure level (copying)	55 dB
Sound pressure level (printing)	54 dB
Sound pressure level (scanning)	56 dB
Control type	Touch
Display diagonal	7 \
Market positioning	Business
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security algorithms	LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Maximum duty cycle	200000 pages per month
Page description languages	PCL 5e, PCL 6, PDF 1.6, PostScript 3, PPDS, xHTML
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR
Certification	Blue Angel (RAL-UZ-122), CE Class A, CB IEC 60950-1, IEC 60825-1, IEC 61000-3-2, IEC 61000-3-3, EN 55022 Class A, EN 55024, CISPR 22 Class A, IEC 60320, GS (TÜV), EN 60825-1, ACMA A-tick mark Class A, AS/NZS 60950-1, EK Mark, KCC MIC Mark, CCC Class A, UL AR, CS, TÜV Rh
