Lexmark XM1246 - Page 336

Assembly 6: Electronics 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X1988 1 1Sensor (cartridge
barrel)
“Cartridge barrel shutter sensor kit
removal” on page 236
2 41X1162 1 1 Toner cartridge smart
chip contact
“Toner cartridge smart chip contact
removal” on page 233
3 41X2260 1 1 Sensor (bin full) --
4 41X1209 1 1 Sensor (front door)
“Sensor (front door) removal” on
page 251
5 41X1236 1 1 Interconnect cable
“Interconnect cable removal” on
page 225
6 41X1238 1 1 Sensor (tray present)
“Sensor (tray present) removal” on
page 227
7 41X1210 1 1 Sensor (MPF paper
present)
“Sensor (MPF paper present) removal”
on page 257
7017-2xx, -4xx, -6xx
Parts catalog
336
