Lexmark XM5100 Series Quick Reference

2 Remove the toner cartridge.
3 Remove the imaging unit.
Warning—Potential Damage: Do not expose the imaging
unit to direct light for more than 10 minutes. Extended
exposure to light may cause print quality problems.
4 Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
1
2
5 Insert the imaging unit.
Note: Use the arrows on the side of the printer as guides.
6 Insert the toner cartridge.
Note: Use the arrows on the side of the printer as guides.
7 Close the multipurpose feeder door and the front cover.
1
2
20
