4-5. Using the driving support systems
Use the meter control switches to
enable/disable the RCD function.
(P.108)
1 Press or to select .
2 Press or to select “PKSA”
and then press “OK”.
3 Press or to select “RCD”
and then press “OK”.
When the RCD function is disabled, the
RCD OFF indicator (P.92) illuminates
on the multi-information display.
If the rear camera detection function
detects a pedestrian in the detection
area, the buzzer and pedestrian detec-
tion will operate as follows:
If a pedestrian is detected in area
Buzzer: Sounds repeatedly
Pedestrian detection icon: Blinks 3
times and then stays on
If a pedestrian is detected in area
Buzzer (When the vehicle is sta-
tionary): Sounds 3 times
Buzzer (When the vehicle is back-
ing up, when a pedestrian
approaches the rear of the vehicle):
Sounds repeatedly
Pedestrian detection icon: Blinks 3
times and then stays on
If the system determines that your
vehicle may collide with a pedes-
trian in area
Buzzer: Sounds repeatedly
Pedestrian detection icon: Blinks 3
times and then stays on
Q The rear camera detection function is
operational when
O The power switch is in ON mode.
O RCD function is on.
O The shift lever is in R.
Q Setting the buzzer volume
The buzzer volume can be adjusted on the
multi-information display. (P.270)
The RCD buzzer volume is linked with the
RCTA buzzer volume.
Q If “Rear Camera Detection Unavailable
Remove Dirt from Rear Camera” is dis-
played on the multi-information display
A rear camera lens may be dirty or covered
with snow or ice. In such cases, if it is
removed from the rear camera lens, the
system should return to normal. (It may be
necessary to drive the vehicle for some time
before the system returns to normal.)
Q If “Rear Camera Detection Unavail-
able” is displayed on the multi-informa-
tion display
O If this message is displayed after the 12-
volt battery has been disconnected and
Turning the RCD function on/off
When a pedestrian is detected
A
A
B
B
C
